Applicable working conditions:
High-speed rescue vehicle transport
| PROJECT | UNIT | QZP0812ABD6 |
| Maximum bearing mass of slab | kg | 8000 |
| Rated traction of winch | kN | 80 |
| Plate mechanism length and width | mm | 7200×2540 |
| Height of platform panel from ground | mm | 1270 |
| Chassis type | – | DFH1180EX8 |
| wheel base | mm | 5800 |
| engine type | – | B6.2NS6B230 |
| power | kW | 169 |
| curb weight | kg | 13935 |
| Permitted passenger number | – | 3.2 |
| Optional crane model | – | SQZ160 |
